IPC2328SBR5-DPZ
  • IPC2328SBR5-DPZ
  • IPC2328SBR5-DPZ
  • IPC2328SBR5-DPZ
BDTSecure2328SBR5PZ
Description

• 1/2", progressive scan,CMOS
• Up to 3840×2160 resolution,20fps
• 2.8~12 mm
• Smart IR, up to 50m IR distance
• 2D/3D DNR, ROI, 9:16 corridor mode, ONVIF
• Ultra 265,H.265,ONVIF
• DC12V,PoE.Wide voltage range of ±25%
• IP67


View specifications

BDTSecure2328SBR5PZ 8MP WDR (Motorized) VF Network IR Bullet Camera V.1.6.pdf



Optics

* Day/night functionality

* Optical glass window with higher light transmittance

* IR anti-reflection window to increase the infrared transmittance

* Smart IR, up to 50m (164 ft) IR distance

* Up to 120 dB Optical WDR(Wide Dynamic Range)

* 2D/3D DNR(Digital Noise Reduction)

Compression

* Ultra 265, H.265, H.264, MJPEG

* Embedded smart algorithm

* Triple streams

* ROI (Region of Interest)

* 9:16 corridor mode

Network

* ONVIF Conformance

Structure

* Support PoE power supply

* Wide temperature range: -35°C to 60°C (-31°F to 140°F)

* Wide voltage range of ±25%

* IP67

* 3-Axis
